800 Series ORVR
800 Series ORVR
The HEALY™ 800 Series Onboard Refueling Vapor Recovery (ORVR) nozzle converts any new or existing dispenser to a CARB certified system for ORVR compatibility. The smart interface design will automatically detect whether a vehicle is equipped with ORVR to prevent over-pressurization caused by clean air being pulled back into the storage tank.
Available for use outside of the United States.
- ORVR compatible for underground tank systems without the need for a back-end processor.
- Fills cars faster with high flow rates, while the vacuum-assisted design keeps customers and forecourts clean with its dripless and spitless technology.
- Easy-to-use, durable design that captures the vapors through a reduced size boot.
- Over horizontal shut-off and no-pressure, no-flow technologies for safety.
- Available for full-service applications with three position hold-open clip.
- Available as self-service without hold-open clip.
- Weight: 3.5 Lbs (1.6 Kg)
- Flow rate: 10 gpm (37.85 lpm)
Approvals/Certifications
- UL listed (UL 2586)
- CARB approved
| Model Number | Description |
|---|---|
| 800-02G3 FS-3 |
800 ORVR compatible nozzle, unleaded, full-service, three position hold open-clip, with black scuffguard |
| 405219902 | 800 nozzle mini-boot with face seal and 640956 boot clamp |
| 405220907 |
800 Series nozzle replacement spout kit, includes 405923901 spout
assembly, 6206-OR O-ring kit, 405800901 boot assembly and 640956 boot
clamp |
| 405221902 |
800 nozzle three position hold-open clip kit includes 6238-2 hold-open
clip, 239-L rear guard rivet, 6249 spring, 6130-4 lever assembly, 240-SS
pal nut, 219 front guard rivet, 6358 hand guard, and 235-C lever cover |
| 469 | Nozzle handle cover |
| 6408 | Nozzle scuffguard, black |
| 6408BL | Nozzle scuffguard, blue |
| 6408G | Nozzle scuffguard, green |
| 6408GD | Nozzle scuffguard, gold |
| 6408R | Nozzle scuffguard, red |
| 6408W | Nozzle scuffguard, white |
| 6408Y | Nozzle scuffguard, yellow |
- Nozzles are supplied with black scuffguards unless otherwise specified. To order a nozzle with a scuffguard color other than black, place appropriate “X” code after “G3” in the model number as follows: BL for blue, GD for gold, G for green, R for red, W for white, Y for yellow, BG for bright green, PK for pink, or PL for purple.
