EVO™ 200 & EVO™ 400
EVO™ 200 & EVO™ 400
EVO™ 200 & EVO™ 400 provide highly accurate inventory management and containment monitoring for small to mid-size fuel systems. With pre-configured hardware and customizable software options, the EVO™ 200 & EVO™ 400 provide straightforward tank level monitoring and compliance.
Their simple setup and operation, remote connectivity, and advanced security features protect your fuel system while keeping you directly connected to vital site data whenever, and wherever. The highly-intuitive, full-color, icon-based touch screen provides user-friendly on-site access to inventory, alarm, and compliance data.
NEVER STOP EVOLVING
We are driven by our pursuit to innovate, simplify, secure, and connect every station owner to their fuel management system. EVO™ 200 and EVO™ 400 ATGs feature simple setup and operation, remote connectivity, and advanced security features to protect your fuel system while keeping you directly connected to vital site data whenever, and wherever.
Input Capacity
EVO™ 200 can support any combination of up to 6 sensors and probes, while the EVO™ 400 can support any combination of up to 14 sensors and probes.
Turbine Pump Interface
Enhanced remote pump monitoring and control including pump-in-water automation, clogged intake escalation, tank leveling, and tank priority.
Remote Communication
The FFS PRO™ Connect web interface allows users to securely connect directly to an EVO™ Series ATG from any web enabled device.
Inventory Reconciliation
Inventory Reconciliation is an automated leak detection function that analyzes tank volume, deliveries, and sales data to detect fuel loss or gains with a high level of accuracy.
Tank Autocalibration
Eliminate discrepancies in delivery reporting and daily reconciliations caused by inaccurate tank information programmed into the ATG with this function that automatically generates a highly accurate tank strapping chart.
NEW: Flow Rate Monitoring
Detect and react to potential slow flow issues with automated daily reporting and alarms, helping to improve flow rates and dispenser throughput.
A full-color 7” LCD touchscreen serves up one of the most intuitive user interfaces available with simplified user features you won’t find anywhere else. You choose your home screen, you program your product colors, and you choose what shows up on your Favorites screen. Customize the interface to meet your business needs the way you operate. Check out the interactive demo below. Note: Certain features are only available on the EVO™ 600/6000.
CLICK ON THE INTERACTIVE TOUCHSCREEN BELOW
Icon-Based Design
Designed to be understood easily and operated intuitively. It’s simple to operate for new users and can reduce the amount of training required to operate.
One Touch Buttons
You can customize these home screen buttons to automate and carry out anything from complex, multi-function processes to simple daily delivery report generation - all with the touch of a single button.
Quick Jump Menu
Navigate quickly from application to application with ease. This time-saving menu makes the interface’s structure extremely shallow, simple to navigate, and reduces the amount of steps it takes to accomplish tasks.
EVO™ Series ATGs help keep sites in compliance while providing marketers with the highest level protection from the security threats facing our industry.
User Roles
Customizable user roles and log-in security protect against unwanted access and track user activity.
Data Back-Up
Stores up to 3-years of data to provide back up security from power outages or other system interruptions.
Secure WiFi
Optional WiFi allows secure and protected onsite viewing of inventory levels for fuel delivery drivers.
The FFS PRO® Connect web interface allows you to securely connect directly to your EVO™ Series ATG from any web enabled device. It automatically scales for tablets and smart phones, meaning no app to download.
INTERACTIVE DEMO
FFS PRO® CONNECT
FFS PRO® Connect displays real-time data allowing precise delivery scheduling and efficient site management. It also provide immediate notification of alarms so quick corrective actions can be taken.
Turbine Pump Interface is a powerful tool that creates a network between your Submersible Turbine Pump (STP) controllers and EVO™ Series ATGs. Through TPI, the tank gauge can be programmed to respond to faults in the submersible pumping system and react with intelligence that pump controllers alone cannot.
SEE TPI IN ACTIONPump In Water Automation
When the water level in a tank approaches the pump intake, the tank gauge will enter alarm mode and automatically shut down the pump, protecting the system and consumers from water being pumped from that tank.
Leveling & Priority Modes
When managing two storage tanks of the same product ‘Leveling Mode’ can keep both tanks at the same percentage full without the use of a syphon bar between the two tanks.
Remote Pump Interaction
By networking the intelligent controllers to the fuel management system via TPI, a technician can remotely connect to the site to review the logged event history and view the status.
Improve dispenser throughput and maintain fast flow rates with the ability to detect and react to potential slow flow issues before they impact business with Flow Rate Monitoring. Available as a software option on new EVO™ Series ATGs or as a field upgrade option, Flow Rate Monitoring delivers ongoing flow rate performance data, flow rates for each fueling point, and provides a notification if transactions dip below a user-defined set point.
FLOW RATE MONITORING SELECTION GUIDEKnow Your Flow
Monitor for and ensure fast and consistent dispenser throughput with daily reports and alarm notifications regarding flow rate performance.
Performance Monitoring
Sales and dispensing duration data are automatically reconciled to help you better understand the flow performance of every fueling point.
Proactive Maintenance
Often, slow flow rates can indicate that a dispenser filter needs to be changed. Be proactive in calling for maintenance, getting dispensers back to peak performance sooner.
The EVO™ Series family of ATGs offers four different options with right-sized features to meet the requirements of your specific application, size, and compliance needs. Which ATG is right for your application?
ATG SELECTION GUIDEWith pre-configured hardware and customizable software options, these ATGs provide straightforward tank level monitoring and compliance. Their simple setup and operation, remote connectivity, and advanced security features protect your fuel system while keeping you directly connected to vital site data whenever, and wherever.
- Included Features: Inventory monitoring, Turbine Pump Interface (TPI) capability for enhanced and automated submersible turbine pump control, static tank testing, and containment compliance monitoring.
- Optional Features: 24-hour Statistical Continuous Automatic Leak Detection (SCALD®), tank autocalibration, inventory reconciliation, and flow rate monitoring.
- Both the EVO™ 200 & EVO™ 400 feature the capability to interface with probes and sensors in any combination up to 6 (EVO™ 200) or 14 (EVO™ 400).
- Customizable user roles and log-in security features protect against unwanted access while keeping track of user activity
within your system.
- Streamlined setup and programming includes hardware auto-detection and wiring confirmation, multipoint tank charting, network printer auto-detection, and the ability to download and upload entire programming profiles from one to another.
- Intuitive full-color 7" (17.78 cm) LCD touch screen interface provides simplified on-site access features including:
- Up to Six (6) One Touch Buttons that are custom programmed to carry out common automated tasks with a single tap.
- A Quick Jump Menu that allows you to quickly maneuver from application to application using a single button.
- Programmable product colors for each tank.
- FFS PRO® Connect allows you to remotely connect to your EVO™ from any web-enabled device.
- Optional WiFi allows secure and protected on-site viewing of inventory levels for fuel delivery drivers.
- Supports MQTT protocol, the standard for IoT messaging, for enhanced security of data transmission.
Components
- Cover
- LCD touch screen
- LED indicators
- Anunciator (audible alarm)
- RS-485
- Mini USB port
- Ethernet / USB port
- RS-232
- Knockouts
- Mounting holes
- Flip up panel (touch screen)
- Termination blocks
- Main board
General
| Maximum tanks monitored | 6 (EVO™ 200)/14 (EVO™ 400) |
| Maximum sensor input capacity | 6 (EVO™ 200)/14 (EVO™ 400) |
| Lines capacity | 6 (EVO™ 200)/14 (EVO™ 400) |
| Dry contact input channels | 2 |
| Relay output channels | 2 |
| Connectivity | Ethernet, RS-232, RS-485, standard USB, Mini-B USB, and WiFi (optional) |
| Display type | 7" (17.78 cm) color LCD touch screen |
| Printer type | External (network or USB) |
| Alarm | Internal audible alarm |
| LEDs | Alarm, warning, and power |
| Tank chart correction points | 7,500 |
| Applicable liquids | Petroleum, chemicals, and waste |
| Level units | Inches, centimeters, and millimeters |
| Volume units | Gallons or liters (mass with density option) |
| Power requirements | 110 to 240 VAC, 50/60 Hz, 2.6 Amps |
| Operating temperature | 32° to 104° F (0° to 40° C) |
| Humidity | 0-95% non-condensing |
| Dimensions | H: 8" (205 mm), W:13 ¾" (350 mm),D: 3¼" (83 mm) |
| Alarm set points | High/low product, water, and temperature |
| Technical Advantages | Inventory reconciliation/tank autocalibration/flow rate monitoring (optional) |
| Measurements | Density, mass, and phase separation measurement |
| Notifications | Email and SMS |
| Programming | Conditions |
| Monitoring | Back-up generator |
| Support | MODBUS™ |
| Approvals | UL, cUL, ATEX, IECEx, GSA IT Security |
| Certifications |
|
Ordering Guide
ATG model, software and hardware options can be listed separately or combined when ordering. Systems shipped from the factory will list the combined part number. Complete part numbers have a specific order and are created using the following guidelines:
EVOX DW - TRFC
- EVOX = Base Model Options
- EVO200 = EVO™ 200 base model, up to 6 channels
- EVO400 = EVO™ 400 base model, up to 14 channels
- DW = Hardware Options (choose all that apply)
- D = Display (color LCD touch screen)
- W = WiFi
- TR = Software Options (choose all that apply)
- T = SCALD 24-hour tank testing
- R or F
- R = Reconciliation/Autocalibration
- F = Reconcilliation/Autocalibration with flow rate monitoring
- C = Enhanced logic conditions including value, counter, value compare, and latch
Example: EVO400DW-TR = EVO™ 400 base model, up to 14 channels with display, with Wifi, with SCALD, and with Reconciliation/Autocalibration.
EVO™ 200 & EVO™ 400 Hardware & Software Field Upgrades
The following software and hardware options can be added to customize your EVO™ once it's been installed in the field.
Internal Software Field Upgrades
| Model Number | Description |
|---|---|
| TS-TT | Statistical Continuous Automatic Leak Detection (SCALD®) 24-hour tank testing |
| TS-TRAC | Tank inventory reconciliation and autocalibration |
| TS-TRAC-F | Reconciliation/autocalibration and flow rate monitoring |
| TS-FLOW | Flow rate monitoring |
| TS-CON | Enhanced logic conditions including value, counter, value compare, latch, and DEF/AdBlue® recirculation |
Hardware Field Upgrades
| Model Number | Description |
|---|---|
| FMP-LCD | (D) Display (color LCD touch screen) |
| FMP-WIFI | WiFi upgrade for an existing EVO™ 200/400, EVO™ 600/6000, includes 4.5" antenna |
| FMP-ETP | External thermal printer, includes USB cable, power cord, one roll of thermal printer paper, and wall mount hardware |
- Note: The external printer measures 5.6" w x 5.2" h x 8.0" d (142 mm x 132 mm x 204 mm) and can be mounted to wall next to the EVO™ using the included hardware.
External Printer
| Model Number | Description |
|---|---|
| FMP-EPPC | Case of 25 thermal printer paper rolls |
| FMP-ETP | External thermal printer, includes USB cable, power cord, one roll of thermal printer paper, and wall mount hardware |
- The external printer measures 142mm X 132mm X 204mm (w x h x d) and can be mounted to wall next to the EVO™ Series ATG using the included hardware).
EVO™ 200 and EVO™ 400 Replacement Parts
| Model Number | Description |
|---|---|
| FMSP-24MB | EVO™ 200 and EVO™ 400 replacement main board |
| FMSP-SOM | Unregistered, replacement SOM (no WIFI) |
| FMSP-SOM-R | Registered replacement SOM (no WIFI) |
| FMSP-UDP200 | EVO™ 200 replacement input PCB |
| FMSP-UDP400 | EVO™ 400 replacement input PCB |
| FMSP-LCD | EVO™ 200 and EVO™ 400 LCD replacement |
| FMP-24FUSE | EVO™ 200 and EVO™ 400 replacement fuse kit |
| FMP-24TRMBLK | EVO™ 200 and EVO™ 400 replacement terminal blocks |
| FMSP-24CVR | EVO™ 200 and EVO™ 400 without LCD replacement cover |
| FMSP-24CVRWD | EVO™ 200 and EVO™ 400 with LCD replacement cover |
| FMP-EPPC | Case of 25 thermal printer paper rolls |
| FMP-ETP | External thermal printer, includes USB cable, power cord, one roll of thermal printer paper, and wall mount hardware |
- The serial number of the old SOM must be provided when ordering the FMSP-SOM-R or the FMSP-SOMW-R.
