Fixed Speed Single Phase

Guardian Single Phase - Hero.psd

Fixed Speed Single Phase

The Guardian Series™ single phase controller provides intelligent submersible turbine pump (STP) control and protection for fixed speed pumps.

A MAJOR LEAP FORWARD IN PUMP CONTROL

Built upon the solid FE PETRO® brand smart controller platform, Guardian Series™ controllers feature an enhanced user interface, greater functionality, and higher performance compared to standard control boxes.

GET MORE OUT OF YOUR PUMP CONTROLLER

Guardian Series™ intelligent pump controllers let station owners get the most out of their fixed speed pump controller with enhanced functionality and communication capabilities as well as simplified setup and operation.

Guardian Series - Intelligent.psd

INTELLIGENT PUMP CONTROL

Intelligently control STPs with features including dry run prevention, fault status notifications, and the ability to communicate remotely with STPs via the Automatic Tank Gauge (ATG).

Guardian Series - Setup.psd

EASY SETUP

With a single press of the “Calibrate” button, the controller will automatically learn the electrical characteristics of the STP.

Guardian Series - Troubleshooting.psd

FASTER TROUBLESHOOTING

Service technicians can quickly review the last five abnormal conditions via the LCD display, allowing for faster troubleshooting of intermittent conditions.

ENHANCED USER INTERFACE

The all-new Guardian Series™ user interface includes features designed to make setup, operation, and maintenance easier for every user.

Guardian Series - Interface Wide.psd

1. LCD Display

A 3½” digit LCD display provides readable running and fault status for improved troubleshooting.

2. Output Conditions

Readable output conditions are listed on the front panel for quick reference.

3. User Interface

Separate Reset and Silence/Calibrate push buttons provide clear interaction with the controller.

4. Communication LED

A yellow LED provides a visual confirmation of communication between the controller and the STP.

UPDATED RELIABILITY, PROTECTION, & COMMUNICATION
Guardian Series - Updated Wide.psd

Reliability

Updated surge protection and pump relay circuitry improves the controller’s ability to handle challenging incoming power.

Protection

Over voltage protection and enhanced underload detection better protects pumping system equipment.

Communication

Updated RS-485 communication provides seamless manifolded pump and Turbine Pump Interface operation.

ADVANCED SUBMERSIBLE PUMP CONTROL

TPI is a powerful tool that creates a network between the Guardian™ Series controller and EVO™ Series Automatic Tank Gauges (ATGs). Through TPI, the ATG has access to the submersible pumping system status and the capability to react with intelligence that pump controllers alone cannot. The devices share data to provide enhanced system capabilities.

EVO 600 Guardian Series TPI Wide.psd

TPI Capabilities

Remote access to STPs

Response automation

STP history reporting

Pump in water prevention

Clogged STP intake escalation

Overfill protection and automation

Primary and secondary pump management

Adjusted pump priority (leveling on the fly)

Advanced pump control

  • Compatible with FE PETRO® single-phase 2 Hp, 1½ Hp, ⅓ Hp, and ¾ Hp fixed speed STPs, as well as comparable competitive STPs.

  • 3½ digit LCD provides readable running and fault status for quick troubleshooting.
  • Separate “Reset” and “Silence/Calibrate” push buttons provide clear interaction with the controller.

  • Automatically logs the last five abnormal conditions seen in the pumping system. This data is retained in non-volatile memory. Service technicians can quickly view a history of abnormal conditions, which is particularly useful when troubleshooting intermittent conditions.
  • Over voltage protection and enhanced underload detection protects pumping system equipment.

  • With a single press of the “Calibrate” button, the controller will automatically learn the electrical characteristics of the STP for easy setup or retrofit.

General

  • Dimensions: 8½” × 5” × 3” (215 mm × 127 mm × 76 mm)

  • Motor contact rating: 2 Hp, 200-250 VAC, 50/60 Hz, Single Phase

  • Switch hook rating: 120-240 VAC, 50/60 Hz

  • An integrated RS 485 com port is provided to connect Guardian Series™ Controllers to EVO™ Series automatic tank gauges (ATGs) for enhanced functionality via Turbine Pump Interface (TPI).

Approvals/Certifications

  • cULus listed.

  • CE certified.

  • ISO 9001:2015 certified manufacturer.

Guardian Series™ Single Phase Controller

Model Number Description
5800100220 SPGC-220 Guardian Series™ Single-Phase Controller, 220 Volt
402312932 STP-DHIB + SPGC-220 Guardian Series™ Single-Phase Controller bundle (220 Volt supply, 240 Volt hook)
402312931 STP-DHI + SPGC-220 Guardian Series™ Single-Phase Controller bundle (220 Volt supply, 110 Volt hook)
  • Compatible with all single-phase FE PETRO® and competitive model STPs.
  • One controller required for each submersible (up to 2 Hp).
  • Compatible for use in primary/secondary configurations with STP-SCI models.

Replacement Parts

Model Number Description
225005932 SPGC-220 lower (power, relay) replacement board
225000932 SPGC-220 upper (user input) replacement board
